| CellChemistry | LiFePO4 |
| Module Energy(kWh) | 10.24 |
| Module Nominal Voltage (V) | 51.2 |
| Module Capacity(Ah) | 100 |
| Battery Module Qty in parallel. (Optional) | 1-128 |
| System Nominal Voltage (V) | 51.2 |
| System Operating Voltage (V) | 43.2~57 .6 |
| System Energy (kWh) | 10.24~1310.72 |
| System Usable Energy(kWh) | 10~1280 |
| Working Temperature(°C) | Charge: -10~50/Discharge:-20~55 |
| Display | SOC Status indicator LED indicator |
1C DischargeMax discharge current:200A,simultaneously supplying power to multiple loads.
Flexible InvestmentSupports up to 128 units in parallel, with a total capacity of up to 1310.72 kWh.
IP65 RatingFearless of outdoor installation,strong environmental adaptability
Smart BMSAuto ID. Millisecond level status monitor, real time battery management, and optimization.
Easy InstallationSetup is simple and quick. support wall-mounted, floor-mounted.
Modular DesignCCS process improves consistency and stability.
90% DOD, 0.5C charge & discharge at 25°C. System usable energy may vary due to system configuration parameters.
The current is affected by temperature and SOC.
3 The warranty is due whichever reached first of warranty period or life cycle power.
