| CellChemistry | LiFePO4 |
| Module Energy(kWh) | 16.07 |
| Module Nominal Voltage (V) | 400 |
| Module Capacity(Ah) | 314 |
| Battery Module Qty in parallel. (Optional) | 1-8 |
| System Nominal Voltage (V) | 400 |
| System Operating Voltage (V) | 345~455 |
| System Energy (kWh) | 16.07~128.56 |
| System Usable Energy(kWh) | 15.74~125.92 |
| Working Temperature(°C) | Charge: -10~50/Discharge:-20~55 |
| Display | SOC Status indicator LED indicator |
More Usable Energy90% Depth of Discharge and Pack-Level Energy Optimization.
Flexible Investment16.07 kWh Modular Design, Scalable from 16.07 to 128.56 kWh.
DC BoostDC-DC Voltage boost to 400V, it can be directly matched with high-voltage conventional inverters.
Extended Service LifeIOptimized cycle life exceeds 6000 cycles for long-lasting reliability
IP65 RatingFearless of outdoor installation,strong environmental adaptability
Easy InstallationHigh-voltage DCDC batteries support the mixed use of old and new batteries.
90% DOD, 0.5C charge & discharge at 25°C. System usable energy may vary due to system configuration parameters.
The current is affected by temperature and SOC.
3 The warranty is due whichever reached first of warranty period or life cycle power.
